Toggle Switches
F-Series
The F-Series toggle switches are AC rated
up to 20 amps, single pole, with a slow-
make, slow-break contact mechanism.
These switches are available in a wide
range of ratings, circuits, terminations
and bushing/toggle configurations.
Specifications
?Certifications*: UL, CSA
?Dielectric Strength: 1,000V (minimum)
?Insulation Resistance: 100 Megohms
(minimum)
?Base Material: Phenolic
?Actuator Material: Brass/Nickel Plate
?Bushing Material: Brass/Nickel Plate
* Due to ongoing technological advances, consult factory for
certification specifics.
Dimensional Specifications: in. [mm]
15/32-32UNS-2A
THREAD
.125[3.18] DIA
.187[4.74]
.330[8.38]
.075[1.91] DIA
.437[11.09]
.250[6.35]
.055[1.40] DIA
.394[10.00]
.187[4.74]
KEYWAY
.072[1.82]
.687[17.44]
SOLDER LUG
.250 TAB (Q.C.)
.187 TAB (Q.C.)
X
.465[11.81]
.038[.965] DP
TERMINAL TYPE
.670[17.02]
#6-32NC-2
THREAD
.370[9.39]
.141[3.58]
6.000[152.40]
.500[12.70]
.286[7.26]
.348[8.84]
1.134[28.80]
.634[16.10]
SCREW
(ASSEMBLED)
.062[1.57]
WIRE LEAD
.376[9.55]
.500[12.70] DIA
.038[9.65]
.500[12.70] DIA
.500[12.70] DIA
.125[3.17] DIA
MOUNTING HOLE
WITH KEYWAY
WITH LOCKING RING
2F
A
5
3
-
73 /TABS
SERIES
RATING 1
TERMINATION/FUNCTION 2
2F SINGLE POLE
5
10A 250VAC
SOLDER
.250TAB
SCREW
WIRE
6F SINGLE POLE
MOMENTARY
CIRCUIT
6
15A 125VAC
3/4HP 120-240VAC
3A 250VAC
6A 125VAC
1/4HP 120-240VAC
FUNCTION
ON-NONE-OFF
(ON)-NONE-OFF
ON-NONE-(OFF)
ON-NONE-ON
LUG
3
3
7
3
(QC)
3/TABS
3/TABS
7/TABS
3/TABS
TERM.
4
4
8
4
LEAD
1
1
6
1
A
B
C
ON-NONE-OFF
ON-NONE-ON
ON-OFF-ON
ON-NONE-(ON)
ON-OFF-ON
(ON)-OFF-(ON)
ON-OFF-(ON)
3
3
3
7
3/TABS
3/TABS
3/TABS
7/TABS
4
4
4
8
1
1
1
6
TOGGLE STYLE
TOGGLE
LENGTH
BAT .406
.562
.687
1.00
2.00
BUSHING
LENGTH
.343
.465
.465
.343
.465
SUFFIX
NO.
52
63
73
A2
E3
NEOPRENE
SEAL
57
68
78
A7
E8
NOTES:
BALL .500
.343
22
---
Shading indicates standard configurations.
For bushing accessories, see pages 69 and 70.
1 Additional ratings to 20A available. Consult factory.
2 For .187TAB (QC) type terminal use solder lug function selection codes.
Add the suffix /.187TABS. (ex.) 2FA53-73/.187TABS
Carlingswitch,Inc. (860) 793-9281? Carlingswitch, LTD. Int + 44 1392-364422 ? Carlingswitch Asia-Pacific, LTD. Int + 852-2737-2277
51
